Waterproof Fiberglass Mesh Roll With Good High Temperature Resistance

Waterproof Fiberglass Mesh Roll With Good High Temperature Resistance

fiberglass mesh sheets

fiberglass rendering mesh

Place of Origin:

Wuqiang, China

Brand Name:


Model Number:


Contact Us
Request A Quote
Product Details
Fiberglass Yarn
Mesh Size:
White, Blue, Brown, Yellow, Red
Alkali Content:
Yarn Type:
Payment & Shipping Terms
Minimum Order Quantity
10000 m2
Packaging Details
1 roll in shrink film, then 2 rolls in one woven bag
Delivery Time
15-20 work days
Payment Terms
T/T, L/C, D/P, Western Union
Supply Ability
100000 square meters per day
Product Description

140gsm 10*10mm Fiberglass Mesh White Color 50cm Width For Marble Mosaic




Fiberglass mesh is woven by fiberglass yarns, then alkaline-resistant latex coated. It owns great alkaline-resistant and high strength. As a perfect engineering material in construction, It is widely used to reinforce cement, stone, wall materials, roofing, gypsum and so on.


Fiberglass mesh on the basis of C-glass or E-glass fiberglass woven mesh, then coated with alkali resistant liquid. It possesses properties of high strength, good cohesion, and anti alkali. Fiberglass mesh is woven by fiberglass yarn as its basis mesh, and then coated by alkaline resistant latex. It has fine alkaline-resistant, high strength, etc. As an ideal engineering material in construction, it is mainly used to reinforce cement, stone, wall materials, roofing, and gypsum and so on.




Material of the base:Fiberglass yarn

Type of weave (name):Leno

Hole Size:2.8x2.8mm,4x4mm,5x5mm,10x10mm

Colored fibers woven:White,Green,Blue,Orange,and any color

Coating:Latex Coating, Urea Coating

Length of the roll:30m,50m,100m.

Height of the roll:0.2m,0.5m,1m,1.2m,1.5m,1.8m,

Weighting:45g,80g,100g,110g,120g,150g,160g and so on.


    NO.              Specifications Mesh size
Yarn density
Tensile strength
warp weft warp weft warp weft
1 4×4-75 4 4 48/2 200 75±3 700 850
2 4×4-90 4 4 67/2 200 90±3 950 1100
3 4×4-145 4 4 134/2 240 145±5 1500 1500
4 4×4-160 4 4 134/2 300 160±5 1500 1650
5 4×5-110 4 5 100/2 360 110±5 1100 1200
6 4×5-125 4 5 100/2 280 125±5 1200 1300
7 4×5-145 4 5 134/2 300 145±5 1400 1400
8 4×5-160 4 5 134/2 360 160±5 1500 1600
9 5×5-90 5 5 67/2 240 90±3 950 1150



1. 75g / m2 or less: Used in the reinforcement of thin slurry, to eliminate small cracks and scattered throughout the surface pressure.

2. 110g / m2 or about: Widely used in indoor and outdoor walls, prevent the various materials (such as brick, light wood, prefabricated structure) of treatment or caused by a variety of expansion coefficient of wall crack and break .

3. 145g/m2 or about: Used in the wall and be mixed in various materials (such as brick, light wood, prefabricated structures), to prevent cracking and scatter the whole surface pressure, especially in the external wall insulation system (EIFS ).

4. 160g / m2 or about: Used in insulator layer of reinforcement in the mortar, through shrinkage and temperature changes by providing a space to maintain movement between the layers, prevent crack and rupture due to shrinkage or temperature.




1). High temperature resistance--It can continuously work under-140 to 260, max resist high temperature up to 360.

2). Chemical resistance--It can resist all most of chemical medicines.

3). Permeability--It can avoid wasting heat and improve drying efficiency for it's permeability.

4). Non Stick--It can easily remove all kinds of adhesives such as resin, paint and chemical medicine, easy to clean.

5). Stable dimension, high intensity, elongation coefficient less 5%.

6). Low coefficient of friction and dielectric constant, good insulting ability.

7). Good flex fatigue resistance--It has high tensile strength and excellent flex fatigue resistance. It's better for small wheels.

8). Resistance to UV, IR and HF; Non-toxic, 100%PFOA free
